| Measuring Ranges | Accuracy / Performance |
| C0 : 0 - 10% vol | 0.06 % Abs., 5% Rel. |
| OPTION: CO 0-1000/5000 PPM | 5% Rel. |
| C02 : 0 - 20% vol | 0.03 % Abs., 5% Rel. |
| HC : 0 - 2000 PPM | 4 PPM Abs., 5% Rel. |
HC : 2001-10000 PPM |
5%Relative |
| OPTION: HC as methane based 0-10000 PPM | 5% Rel. |
| O2 : 0 - 25% vol | 0.1 % Abs., 5% Rel. |
| N0: 0 - 1000 PPM | 32 PPM Absolute |
| N0: 1001-2000 PPM | 60 PPM Absolute |
| NO: 2001-4000 PPM | 120 PPM Absolute |
| CLD OPTION: NO/N02:0-30/100 /300/1000/10000 PPM | less then +/- 0.5% of full scale |
| OPTION: SO2 0-100/1000 PPM | 5% Rel. |
| OPTION: N2O 0-500 PPM | 5% Rel. |
| Opacity 0 - 100% | +/- 0.5% Relative |
| Soot density [gr/m3] | +/- 0.5% Relative |
| RPM/oil Temp. | +/- 2% Relative |
| International Standards | |
| ISO | 3930 |
| OIML | R99 Class 1 |
| BAR | 97 |
Dimensions / Weight |
|
| NDIR Analyzer and Host | 56x48x25cm / 14kg |
| CLD Analyzer (option) | 13x48x51 cm / 17.1kg |
| Opacity Meter | 38x24x9 cm / 4.5kg |
