| SMART 2000xfl | Accuracy / Performance |
| Flow range : 1) 0-160 CFM 2) 0-450 CFM | 5% Rel. |
| Gas Temp. 0 - 750 deg.C | 1% Abs. |
| Pressure diff.: 0-40cm H2O ( 0-1.00 VDC ) | 3% Rel. |
| Response Time | 1sec. |
Dimensions / Weight |
|
| Dimensions/Weight | 1) 6x28 cm / 2.1 kg 2)16x42 cm / 3.8 kg |
| SMART 2000dill | Accuracy / Performance |
| Dilution Ratio : 1 - 7.00 | 3% Rel. |
| Flow range : 0 - 5 LPM | 3% Rel. |
| DSR 1000 | Accuracy / Performance |
| Speed range: 0-300 kmh | 2% Abs. |
| Response Time | 1sec. |
*click here for full specification in PDF format  |
|
